モジュール式大口径浮体係留アンカーペンダントブイ
主要 な 特質
ブランド名:
Henger
モデル番号:
004
原産地:
中国
認定:
ISO 9001
最低注文数量:
1
価格:
500
供給能力:
50 PC/週
納期:
15~30 営業日
支払い条件:
L/C,D/A,D/P,T/T
標準パッケージ:
ヌードパッキング
製品概要
モジュール設計 大口径浮遊係留ブイ 製品説明 鋼製係留ブイは、港湾施設における重要な係留インフラとして、さまざまなトン数の船舶を確実に収容できるように細心の注意を払って設計されています。その運用フレームワークは、本質的な利便性と適応性によって定義されています。停泊区域に配備すると、係留プロトコルを合理化し、船舶の交通量の変動に巧みに対応します。 これらのブイは、中核的な係留の役割を超えて、重要な海事活動を可能にします。貨物バージングのための安定したプラットフォームを提供し、バースの制限を回避するために船舶間の積み替えを容易にし、現場での船舶のメンテナンスと修理作業をサポートします。この機能によ...
製品カスタム属性
ハイライト
浮体係留アンカーペンダントブイ
,大口径浮体係留ブイ
,モジュール式アンカーペンダントブイ
製品名:
アンカーペンダントボイ
材料:
鋼,EVAの詰め物
サイズ:
カスタムサイズ
保証:
12ヶ月
色:
カスタムカラー
ロゴ サービス:
カスタマイズ
商標:
Henger
原産地:
中国
デザイン:
モジュール式設計
製品説明
モジュール設計 大口径浮遊係留ブイ
鋼製係留ブイ技術パラメータ
| モデル | 正味浮力 | D×H (m) | 適合船舶トン数 (t) |
| HESMB 2.0 | 3 | 2.0×1.74 | <2000 |
| HESMB 2.6 | 6 | 2.6×2.27 | <5000 |
| HESMB 3.6 | 19 | 3.6×2.14 | <10000 |
| HESMB 5.0 | 28.5 | 5.0×3.4 | <12000 |
| HESMB 5.5 | 31.2 | 5.5×3.0 | <100000 |
| HESMB 6.0 | 34.2 | 6.0×3.2 | <150000 |
| HESMB 8.0 | 40.3 | 8.0×2.46 | <250000 |
アンカーペンダントブイ
アンカーペンダントブイは、幅広いサイズで利用可能で、スーツケースタイプ、モジュール式および非モジュール式、カスタムメイドおよび標準構成から選択できます。すべて、顧客の要件に合わせて構成された取り外し可能な中央鋼製ワークが付属しています。典型的なハンドリング十字/パッドアイ配置または、チェーンではなくアンカーワイヤーで使用するためのスルーハワーズe。
アンカーペンダントブイ技術パラメータ
|
モデル
|
予備浮力 (kg) |
直径 (mm) |
フロート長 (mm) |
全長 (mm) |
重量 (kg) |
|
HE-APB1000
|
1000 | 1350 | 1100 | 1900 | 300 |
|
HE-APB2000
|
2000 | 1500 | 1500 | 2600 | 500 |
|
HE-APB3000
|
3000 | 1850 | 1500 | 2600 | 600 |
|
HE-APB4000
|
4000 | 2000 | 1900 | 2900 | 850 |
|
HE-APB6000
|
6000 | 2500 | 2200 | 3250 | 1000 |
|
HE-APB8000
|
8000 | 2500 | 2200 | 3250 | 1250 |
|
HE-APB10000
|
10000 | 3000 | 2200 | 3500 | 1550 |
|
HE-APB20000 |
20000 | 3500 | 3000 | 4200 | 2400 |
*ブイのサイズと浮力は、顧客の設計に合わせてカスタマイズできます。
ご要望がございましたら、いつでもご連絡ください。お読みいただきありがとうございます。
