Custom Manufacturing Pneumatic Rubber Fender with 24 Months Shelf Life and Safety Valve Included for No Performance Deterioration
主要 な 特質
ブランド名:
Henger
モデル番号:
PRF
原産地:
中国
認定:
ABS, CCS, BV, LR, DNV
最低注文数量:
1
価格:
$347
供給能力:
5/日
納期:
5-8勤務日
標準パッケージ:
パレット
製品概要
Top-Quality Customized Pneumatic Rubber Fender ISO17357 0.3-4.8 M Qingdao Henger Shipping Supplies Co., Ltd Located in Qingdao, a coastal city known for its scenic beauty, Qingdao Henger Shipping Supplies Co., Ltd is a leading high-tech enterprise specializing in marine products. We manufacture ...
製品カスタム属性
ハイライト
24 Months Shelf Life Pneumatic Rubber Fender
,Safety Valve Included Inflatable Marine Fender
,No Performance Deterioration Yokohama Type Rubber Fender
材料:
ゴム
サイズ:
カスタム製造
アプリケーション:
船から船へ
貯蔵寿命:
24か月
プレッシャー:
50KPa及び80KPa
構造:
インフレータブル
製品説明
Top-Quality Customized Pneumatic Rubber Fender ISO17357 0.3-4.8 M
Qingdao Henger Shipping Supplies Co., Ltd
Located in Qingdao, a coastal city known for its scenic beauty, Qingdao Henger Shipping Supplies Co., Ltd is a leading high-tech enterprise specializing in marine products. We manufacture premium marine rubber fenders, marine airbags, navigation marks, and marine buoys, combining cutting-edge research with advanced manufacturing techniques.
Located in Qingdao, a coastal city known for its scenic beauty, Qingdao Henger Shipping Supplies Co., Ltd is a leading high-tech enterprise specializing in marine products. We manufacture premium marine rubber fenders, marine airbags, navigation marks, and marine buoys, combining cutting-edge research with advanced manufacturing techniques.
Our commitment to quality is demonstrated by our ISO 9001:2008 certification and approvals from renowned classification societies including CCS, BV, GL, ABS, and LR. We focus on delivering durable, high-performance products that meet international safety standards.
With advanced technology, complete manufacturing facilities, and rigorous quality control, we strive to be a top international marine products manufacturer, ensuring global marine safety through collaborative partnerships.
Inflatable Rubber Fender Introduction
The Yokohama Type Inflatable Rubber Fender was developed in 1958 and has evolved alongside ship technology to accommodate increasingly larger vessels including VLCCs, ULCCs, gas carriers, and bulk carriers.
These fenders are used worldwide for ship-to-ship (STS) and ship-to-dock (STD) operations, playing a critical role in safe berthing and mooring. Millions have been supplied globally since their introduction.
Inflatable Rubber Fender Technical Parameters
| Fender Size | Compression Amount (60%) | Noumenon Weight (Kg) | Weight with Protective Jacket (Kg) | ||
|---|---|---|---|---|---|
| D (mm) | L (mm) | Reaction (KN) | Energy Absorption (KNm) | ||
| 500 | 1000 | 64 | 6 | 23 | 35 |
- Available in 0.05Mpa & 0.08Mpa internal pressure options
- Custom sizes available upon request
- All accessories can be customized to customer specifications
Henger Inflatable Rubber Fender Advantages
Safety and Reliability
Constructed with multiple layers of strong tire-cord for pressure and cut resistance. Large fenders include safety valves for pressure regulation.
Constructed with multiple layers of strong tire-cord for pressure and cut resistance. Large fenders include safety valves for pressure regulation.
No Performance Deterioration
Utilizes compressive elasticity of air, eliminating performance fatigue over time.
Utilizes compressive elasticity of air, eliminating performance fatigue over time.
Effective at Inclined Berthing
Maintains energy absorption efficiency at compression angles up to 15 degrees.
Maintains energy absorption efficiency at compression angles up to 15 degrees.
Cost Competitive System
Uniform surface pressure makes these fenders ideal for LNG-ship terminals.
Uniform surface pressure makes these fenders ideal for LNG-ship terminals.
Soft Reaction Force
Gradual force increase protects ships and mooring facilities even under excess loads.
Gradual force increase protects ships and mooring facilities even under excess loads.
Weather Resistance
Performs reliably in rough conditions with wide deflection allowance.
Performs reliably in rough conditions with wide deflection allowance.
Inflatable Rubber Fender Applications
- Large crude oil carriers (VLCC)
- Container vessels
- Offshore sea task platforms
- Large shipyards and docks
- Cruise ships and large vessels
- Military harbor docks
- Large bridge piers
