防蝕の浮遊ドックのフェンダー80kpa/50kpaをつなぎ、出荷して下さい

主要 な 特質
ブランド名: Henger
モデル番号: 006
原産地: 中国
認定: CCS.ABS.LRS.BV.GL.DNV.NK
最低注文数量: 1pcs
供給能力: 1週あたりの30 PC
納期: 5 つの仕事日
支払い条件: L/C、D/A、D/P、T/T、ウェスタン・ユニオンL/C、D/A、D/P、T/T、ウェスタン・ユニオン、Moneygram
標準パッケージ: 露出した/パレット

製品概要

防蝕のドックおよび船の浮遊ドックのフェンダー80kpa/50kpa私達にどんなタイプがあるか。 タイヤの純タイプ:多数のタイヤは球に結ばれ、両端は柔軟に回ることができる特別なフライホイールに結ばれる。大きく、信頼できる球のために適した。 ゴム製純タイプ:自由に引き締まるか、または伸ばすことができる球に特別なゴム パッドを結びなさい、絞られた場合。中型および小さい信頼できる球のために適した。 ライン・タイプ:純カバーはナイロン ロープと編まれる;球に堅く結ばれて。それは小型の信頼できる球のために適している。 空気の50のフェンダーのサイズおよび性能要件 わずかなサイズの直径Xの長さ mm 最初の...

製品カスタム属性

ハイライト

海洋のボートのフェンダー

,

膨脹可能な海洋のフェンダー

製品名:
空気のゴム製 フェンダー/海洋のフェンダー/横浜フェンダー
材料:
天然ゴム
指定:
DIA 0.5m-4.5m、L 0.7m-9m/Customized
証明書:
CCS/BV/LR/ISO17357/DNV/SGS
保存性:
24か月
働き圧力:
50kPa/80kPa
適用:
ドック、艦対艦船
耐用年数:
10年
生産時間:
5-10日
付属品:
タイヤの外装/旋回装置/手錠/鎖
色:
黒い/blue/asの条件
製品説明

防蝕のドックおよび船の浮遊ドックのフェンダー80kpa/50kpa

私達にどんなタイプがあるか。

タイヤの純タイプ:多数のタイヤは球に結ばれ、両端は柔軟に回ることができる特別なフライホイールに結ばれる。大きく、信頼できる球のために適した。

ゴム製純タイプ:自由に引き締まるか、または伸ばすことができる球に特別なゴム パッドを結びなさい、絞られた場合。中型および小さい信頼できる球のために適した。

ライン・タイプ:純カバーはナイロン ロープと編まれる;球に堅く結ばれて。それは小型の信頼できる球のために適している。

空気の50のフェンダーのサイズおよび性能要件

わずかなサイズの直径Xの長さ

mm

最初の内部圧力

kPa

保証されたエネルギー吸収(GEA) GEAの偏向(R)の反力 GEAの偏向(p)の外皮圧力(内部圧力)
偏向60±5% kJの最小値 Tolerance±の10%のkN

基準値

kPa

500 x 1000 50 6 64 132
600 x 1000 50 8 74 126
700 x 1500 50 17 137 135
1000 x 1500 50 32 182 122
1000 x 2000年 50 45 257 132
1200 x2000 50 63 297 126
1350 x 2500 50 102 427 130
1500 x 3000 50 153 579 132
1700 x 3000 50 191 639 128
2000年x 3500 50 308 875 128
2500 x 4000 50 663 1381 137
2500 x5500 50 943 2019年 148
3300 x 4500 50 1175 1884 130
3300 x 6500 50 1814 3015 146
3300 x 10600 50 3067 5257 158
4500 x 9000 50 4752 5747 146
4500 x 12000 50 6473 7984 154

空気の80のフェンダーのサイズおよび性能要件

わずかなサイズの直径Xの長さ

mm

最初の内部圧力

kPa

保証されたエネルギー吸収(GEA) GEAの偏向(r)の反力 GEAの偏向(p)の外皮圧力(内部圧力)
偏向60±5% kJの最小値 Tolerance±10%のkN

基準値

kPa

500 x 1000 80 8 85 174
600 x 1000 80 11 98 166
700 x 1500 80 24 180 177
1000 x 1500 80 45 239 160
1000 x2000 80 63 338 174
1200 x 2000年 80 88 390 166
1350 x 2500 80 142 561 170
1500 x 3000 80 214 761 174
1700 x 3000 80 267 840 168
2000年x 3500 80 430 1150 168
2500 x 4000 80 925 1815 180
2500 x 5500 80 1317 2653 195
3300 x 4500 80 1640 2476 171
3300 x 6500 80 2532 3961 191
3300 x 10600 80 4281 6907 208
4500 x 9000 80 6633 7551 192
4500 x 12000 80 9037 10490 202

いかにフェンダー仕事か。

衝突および衝突の影響を防ぐためにつなぐとき、船により多くの柔軟性および柔軟性があるように空気のフェンダーがか膨脹可能なゴム製 フェンダーまたは横浜フェンダーは緩衝媒体として圧縮空気船の影響エネルギーを吸収するのに使用されている。

防蝕の浮遊ドックのフェンダー80kpa/50kpaをつなぎ、出荷して下さい 0

空気のゴム製 フェンダーの紹介:

膨脹可能なゴム製 フェンダーは(球によって)圧縮空気から成っている海洋のanti-collisionプロダクトである。衝突および衝突回避の効果を達成するためにつなぐとき吸収するのに、緩衝媒体として圧縮空気が主に船をより適用範囲が広くおよび柔らかくさせる船の影響エネルギーを使用されている。横浜タイプ ボール一種の外装のタイプ ボールである。通常航空機のタイヤがか設計のタイヤは球を包むのに使用されている。両端は艦対艦の転送操作および船の停泊操作のために広く利用されている肩ひもが装備されている。待ち時間。サイズは次のとおりである:D0.5m X L1.0m | D3.3m X L6.5m。膨脹可能なフェンダーは世界中にISO17357-2002およびGB/T 21482-2002の国際的な品質規格の厳密な調和、およびプロダクトで(球によって)輸出される作り出される。

防蝕の浮遊ドックのフェンダー80kpa/50kpaをつなぎ、出荷して下さい 1

空気のゴム製 フェンダーの特徴:

*いろいろな500のmmから4500のmmまで及ぶサイズ、500のmmから12000のmmまで及ぶ直径および長さで利用できる
*多くの種類の色、黒、乳白色の白、青い軍艦の水平な灰色、オレンジ赤い
*内部のゴム製層のContructed、コードの層および外のゴム製層を補強する
*材料および流体静力学圧力不規則性のために包括的にテストされて
*角および耐久性の性能のために正しく評価されて

*はっきりすべての関連した同一証明と印が付いていた

*最新の証明と完全

防蝕の浮遊ドックのフェンダー80kpa/50kpaをつなぎ、出荷して下さい 2

HENGERの売り上げ後のサービス:

サービスおよび交通機関:


Hengerのプロダクト保証期間は24か月であり、一般の製造者はまた信頼私達であり、顧客が私達の工場プロダクトで持っているあまり長い時間に達することができない。


売り上げ後のサービス私達は私達がそこに常にいる質問がある限り、1日24時間オンラインである、あなたの質問に答え、テクニカル サポートを与える専門スタッフがある。


交通機関私達は顧客の条件に従ってデフレーションなしでデフレーション パレット交通機関および全体のフェンダーの交通機関を取ってもいい。私達は顧客の要求を常に最初に置いた。
